Hydraulic Cylinder

Hydraulic cylinder jacket ：Material：45#steel，Thermal refining：25～30HRC.Adopt the automatic welding, detection treatment; ensure no leakage porosity and welding defects.

1. Piston rod：Hard chromium plating surface treatment, plating chromic layer in theatmosphere and has stronger passivation ability, can keep the metal luster, It can’t produce the chemical reaction in a variety of acid medium. Coating hardness will be reached to 1000 HV, excellent wear resistance.
2. Seal ring: The Parker precision O-rings and block circle, and to ensure the hydrauliccylinder will not have the leakage under high pressure and longtime wear-resisting
3. The hydraulic cylinder surface: the primer is the anti-rusting paint, paint processingouter lacquer.
4. The hydraulic cylinder strictly complies with JB/T 10205- 1500 “The inspectionstandard of hydraulic cylinder technology conditions”. Under the 10 Mpa pressure, there is no external and internal leakage.
5. The hydraulic oil: the viscosity is 46 ~ 68 CST, anti-wear hydraulic oil

Piston and End Cap ( Radial design for the distributing plate)

Piston main parts: Seat Connection, orientation cycle, and active sealing rings, bowl type seal ring, distributor, type of mesh filter board, O-rings, etc.

Piston parts material: SS316L/PTFE/PEEK, all materials meet FDA, NSF standards and the bolt connection between piston and cylinder, very easy to dismounting and the floating piston design will eliminate the coaxial tolerance between hydraulic cylinder and column tube.

The pistons used the three seals design, bowl type of seal ring and active sealing ring and oriented ring, all these will ensure the column tube sealing performance;
